MAX4507CWN
RoHS
/
Package 18-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Specialized ICs
Description
SIGNAL-LINE PROTECTOR
PDF
/
Buying Options
Total Price: USD $9.4
Unit Price: USD $9.3974
≥1 USD $9.3974
≥10 USD $7.7102
≥100 USD $7.46985
≥500 USD $7.22855
≥1000 USD $6.9882
Inventory: 775
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 7.5mm
Length 11.55mm
Height Seated (Max) 2.65mm
Technical
Neg Supply Voltage-Min (Vsup) -8V
On-state Resistance Match-Nom 1Ohm
Neg Supply Voltage-Max (Vsup) -18V
On-State Resistance (Max) 100Ohm
Neg Supply Voltage-Nom (Vsup) -15V
Number of Channels 1
Supply Voltage-Min (Vsup) 8V
Temperature Grade COMMERCIAL
Supply Voltage-Max (Vsup) 18V
Operating Temperature (Max) 70°C
JESD-30 Code R-PDSO-G18
Pin Count 18
Time@Peak Reflow Temperature-Max (s) 20
Reach Compliance Code unknown
Terminal Pitch 1.27mm
Supply Voltage 15V
Number of Functions 8
Peak Reflow Temperature (Cel) 240
Terminal Form GULL WING
Terminal Position DUAL
Applications Control Systems
Terminal Finish TIN LEAD
Type Overvoltage Protection
Number of Terminations 18
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Packaging Tube
Physical
Surface Mount YES
Package / Case 18-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
