HA4344BCBZ
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Specialized ICs
Description
IC CROSSPOINT SWITCH 16SOIC
PDF
/
Buying Options
Total Price: USD $3.92
Unit Price: USD $3.916
≥1 USD $3.916
Inventory: 558
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 16-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Technical
Packaging Tube
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 16
Type Crosspoint Switch
Terminal Finish Matte Tin (Sn)
Applications Video
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number HA4344B
JESD-30 Code R-PDSO-G16
Operating Temperature (Max) 70°C
Supply Voltage-Max (Vsup) 5.5V
Temperature Grade COMMERCIAL
Supply Voltage-Min (Vsup) 4.5V
Number of Channels 4
Neg Supply Voltage-Nom (Vsup) -5V
Off-state Isolation-Nom 70 dB
Neg Supply Voltage-Max (Vsup) -5.5V
Neg Supply Voltage-Min (Vsup) -4.5V
Dimensions
Height Seated (Max) 1.75mm
Length 9.9mm
Width 3.9mm
Compliance
RoHS Status ROHS3 Compliant
