CAP017DG image
Favorite
CAP017DG image
Favorite
RoHS
RoHS RoHS compliant
Package 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Specialized ICs
Description IC CAP DISCHRG 1000V 2500NF 8SO
PDF
/
Buying Options
Total Price: USD $4.54
Unit Price: USD $4.54385
≥1 USD $4.54385
≥10 USD $3.7278
≥100 USD $3.6119
≥500 USD $3.49505
≥1000 USD $3.37915
Inventory: 7006
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 6 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Weight 540.001716mg
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)

Compliance

RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No

Dimensions

Width 3.9mm
Length 4.9mm
Height Seated (Max) 1.75mm

Technical

Input Current 21.7μA
Series Resistance 300kOhm
Clamping Voltage 1kV
Max Supply Voltage 230V
Temperature Grade OTHER
Pin Count 8
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 1.27mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Rated 230V
Applications Converter, ACDC
Min Operating Temperature -10°C
Max Operating Temperature 105°C
Terminal Finish MATTE TIN
Type Capacitor Discharge
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
JESD-609 Code e3
Series CAPZero?
Published 2011
Packaging Tube
