CAP014DG-TL
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Specialized ICs
Description
IC CAPZERO 1000V 1000NF 8-SOIC
PDF
/
Buying Options
Total Price: USD $1.09
Unit Price: USD $1.0912
≥1 USD $1.0912
≥10 USD $0.899624
≥100 USD $0.7656
Inventory: 4564
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Weight 540.001716mg
Technical
Packaging Tape & Reel (TR)
Published 2012
Series CAPZero?
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Type Capacitor Discharge
Terminal Finish MATTE TIN
Max Operating Temperature 105°C
Min Operating Temperature 0°C
Applications Converter, ACDC
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) 40
Pin Count 8
Temperature Grade OTHER
Input Current 21.7μA
Dimensions
Height Seated (Max) 1.75mm
Length 4.9mm
Width 3.9mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
