MCP2036-I/SL
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Specialized ICs
Description
MICROCHIP - MCP2036-I/SL - KEYLESS ENTRY AFE, IND SENSOR, 14SOIC
PDF
/
Buying Options
Total Price: USD $0.55
Unit Price: USD $0.5456
≥1 USD $0.5456
≥10 USD $0.5016
≥100 USD $0.4664
Inventory: 1123
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mounting Type Surface Mount
Package / Case 14-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Number of Pins 14
Technical
Packaging Tube
Published 2009
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
ECCN Code EAR99
Type Sensor Interface
Terminal Finish Matte Tin (Sn) - annealed
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Applications Analog I/O
Subcategory Other Consumer ICs
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Frequency 2MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number MCP2036
Pin Count 14
Power Supplies 3/5V
Temperature Grade INDUSTRIAL
Interface Analog, Serial
Max Supply Voltage 5.5V
Min Supply Voltage 2.7V
Operating Supply Current 6.8mA
Nominal Supply Current 6.8mA
Turn On Delay Time 4 μs
Slew Rate 0.6 V/μs
Resolution 1.375 B
Number of A/D Converters 1
Dimensions
Height 1.25mm
Length 8.65mm
Width 3.9mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
