MAX4507CAP+
RoHS
RoHS compliant
RoHS compliantPackage 20-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Specialized ICs
Description
IC OVERVOLTAGE PROTECTION 20SSOP
PDF
/
Buying Options
Total Price: USD $8.57
Unit Price: USD $8.5712
≥1 USD $8.5712
Inventory: 53
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 5.29mm
Length 7.2mm
Height Seated (Max) 1.99mm
Technical
Neg Supply Voltage-Min (Vsup) -8V
On-state Resistance Match-Nom 1Ohm
Neg Supply Voltage-Max (Vsup) -18V
On-State Resistance (Max) 100Ohm
Neg Supply Voltage-Nom (Vsup) -15V
Number of Channels 1
Supply Voltage-Min (Vsup) 8V
Temperature Grade COMMERCIAL
Power Supplies +-15V
Supply Voltage-Max (Vsup) 18V
Operating Temperature (Max) 70°C
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G20
Pin Count 20
Base Part Number MAX4507
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.65mm
Supply Voltage 15V
Number of Functions 8
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Multiplexer or Switches
HTS Code 8542.39.00.01
Applications Control Systems
Terminal Finish Tin (Sn)
Type Overvoltage Protection
ECCN Code EAR99
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2003
Packaging Tube
Physical
Surface Mount YES
Package / Case 20-SSOP (0.209, 5.30mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
