MAX4506EPA
RoHS
/
Package 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Specialized ICs
Description
IC OVERVOLTAGE PROTECTION 8DIP
PDF
/
Buying Options
Total Price: USD $3.73
Unit Price: USD $3.725792
≥1 USD $3.725792
≥10 USD $3.514897
≥100 USD $3.315939
≥500 USD $3.128248
≥1000 USD $2.951181
Inventory: 5094
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 7.62mm
Length 9.375mm
Height Seated (Max) 4.572mm
Technical
Neg Supply Voltage-Min (Vsup) -8V
On-state Resistance Match-Nom 1Ohm
Neg Supply Voltage-Max (Vsup) -18V
On-State Resistance (Max) 100Ohm
Neg Supply Voltage-Nom (Vsup) -15V
Number of Channels 1
Supply Voltage-Min (Vsup) 8V
Temperature Grade INDUSTRIAL
Power Supplies +-15V
Supply Voltage-Max (Vsup) 18V
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Qualification Status Not Qualified
JESD-30 Code R-PDIP-T8
Pin Count 8
Base Part Number MAX4506
Time@Peak Reflow Temperature-Max (s) 20
Reach Compliance Code not_compliant
Terminal Pitch 2.54mm
Supply Voltage 15V
Number of Functions 3
Peak Reflow Temperature (Cel) 240
Terminal Position DUAL
Technology CMOS
Subcategory Multiplexer or Switches
HTS Code 8542.39.00.01
Applications Control Systems
Terminal Finish Tin/Lead (Sn85Pb15)
Type Overvoltage Protection
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Published 2003
Packaging Tube
Physical
Surface Mount NO
Package / Case 8-DIP (0.300, 7.62mm)
Mounting Type Through Hole
