PC942J00000F
RoHS
/
Package 8-DIP (0.300, 7.62mm)
Category Isolators / Special Purpose
Description
OPTOISO 5KV OPIC 8DIP
PDF
/
Inventory: 7965
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Technical
Common Mode Transient Immunity (Min) 10kV/μs
Propagation Delay tpLH / tpHL (Max) 5μs, 5μs
On-State Current-Max 0.5A
Current - DC Forward (If) (Max) 25mA
Forward Current-Max 0.025A
Current - Output / Channel 500mA 600mA
Rise / Fall Time (Typ) 200ns 100ns
Fall Time (Typ) 1 μs
Rise Time 1μs
Direction Unidirectional
Max Output Voltage 18V
Input Type DC
Propagation Delay 5 μs
Voltage - Forward (Vf) (Typ) 1.1V
Number of Channels 1
Configuration COMPLEX
Number of Elements 1
Voltage - Isolation 5000Vrms
Approval Agency UR
Voltage - Supply 5.4V~13V
Max Power Dissipation 550mW
Additional Feature UL RECOGNIZED
Terminal Finish Tin/Copper (Sn/Cu)
Type Power Transistor Driver
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e2
Series OPIC?
Published 2005
Packaging Tube
Operating Temperature -20°C~80°C
Physical
Number of Pins 8
Package / Case 8-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
