PC942
RoHS
/
Package 8-DIP (0.300, 7.62mm)
Category Isolators / Special Purpose
Description
OPTOISO 5KV OPIC 8DIP
PDF
/
Buying Options
Total Price: USD $0.83
Unit Price: USD $0.8303
≥1 USD $0.8303
≥10 USD $0.68115
≥100 USD $0.66025
≥500 USD $0.6384
≥1000 USD $0.6175
Inventory: 530
Minimum: 1
-
+
Technical Details
Technical
Voltage - Forward (Vf) (Typ) 1.1V
Propagation Delay 2 μs
Input Type DC
Output Current per Channel 500mA
Rise Time 200ns
Rise / Fall Time (Typ) 200ns 100ns
Current - Output / Channel 500mA 600mA
Forward Current-Max 0.025A
Current - DC Forward (If) (Max) 25mA
On-State Current-Max 0.5A
Propagation Delay tpLH / tpHL (Max) 5μs, 5μs
Common Mode Transient Immunity (Min) 10kV/μs
Number of Channels 1
Configuration COMPLEX
Number of Elements 1
Voltage - Isolation 5000Vrms
Approval Agency UR
Reach Compliance Code unknown
Voltage - Supply 5.4V~13V
Additional Feature UL RECOGNIZED
Terminal Finish Tin/Lead (Sn/Pb)
Type Power Transistor Driver
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e0
Series OPIC?
Published 2003
Packaging Tube
Operating Temperature -20°C~80°C
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
Physical
Package / Case 8-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
