HCPL-2602-500E
RoHS
RoHS compliant
RoHS compliantPackage 8-SMD, Gull Wing
Category Isolators / Special Purpose
Description
Optocoupler Logic-Out Open Collector DC-IN 1-CH 8-Pin PDIP SMD T/R
PDF
/
Buying Options
Total Price: USD $6.98
Unit Price: USD $6.9784
≥1 USD $6.9784
≥10 USD $5.05824
≥100 USD $4.17956
≥500 USD $3.66043
Inventory: 814
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Common Mode Transient Immunity (Min) 1kV/μs
Propagation Delay tpLH / tpHL (Max) 75ns, 75ns
On-State Current-Max 0.05A
Input Current 60mA
Reverse Breakdown Voltage 950mV
Rise / Fall Time (Typ) 24ns, 10ns
Fall Time (Typ) 10 ns
Rise Time 24 ns
Output Current per Channel 50mA
Direction Unidirectional
Data Rate 10 Mbps
Response Time 1e-7 ns
Forward Current 60mA
Turn On Delay Time 75 ns
Input Type AC, DC
Propagation Delay 75 ns
Voltage - Forward (Vf) (Typ) 2.3V
Output Current 50mA
Power Dissipation 40mW
Number of Channels 1
Configuration COMPLEX
Number of Elements 1
Max Output Current 50mA
Output Voltage 5.5V
Voltage - Isolation 3750Vrms
Approval Agency CSA, UR
Supply Voltage 5.5V
Voltage - Supply 4.5V~5.5V
Max Power Dissipation 40mW
Subcategory Optocoupler - IC Outputs
Additional Feature OPEN COLLECTOR, UL RECOGNIZED, TTL COMPATABLE
Terminal Finish Matte Tin (Sn)
Type Line Receiver
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2013
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 8
Package / Case 8-SMD, Gull Wing
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 17 Weeks
Alternative Model
