SP-4009Y
RoHS
RoHS compliant
RoHS compliantPackage /
Category Audio Products / Speakers
Description
SPEAKER, 88DB SENSITIVITY, 40MMX
PDF
/
Buying Options
Total Price: USD $2.41
Unit Price: USD $2.4112
≥1 USD $2.4112
≥10 USD $1.99408
≥100 USD $1.84096
≥500 USD $1.72964
≥1000 USD $1.62272
≥3000 USD $1.501896
Inventory: 99
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.331 8.40mm
Technical
Efficiency - Testing 100mW/100mm
Efficiency - Type Sound Pressure Level (SPL)
Efficiency - dBA 88.00
Port Location Top
Power - Rated 1W
Frequency Range 0Hz~12kHz
Power - Max 1.5W
Frequency - Self Resonant 600Hz
Impedance 8Ohm
Technology Magnetic
Type General Purpose
Termination Solder Eyelet(s)
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Size / Dimension 1.575Lx0.787W 40.00mmx20.00mm
Series SP Micro Speaker
Operating Temperature -20°C~60°C
Physical
Material - Magnet Nd-Fe-B
Shape Rectangular
Supply Chain
Factory Lead Time 8 Weeks
