SP-1609S-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Audio Products / Speakers
Description
SPEAKER 8OHM 500MW TOP PORT 82DB
PDF
/
Buying Options
Total Price: USD $2.02
Unit Price: USD $2.024
≥1 USD $2.024
≥10 USD $1.68168
≥100 USD $1.553376
≥500 USD $1.45992
≥1000 USD $1.369984
≥3000 USD $1.275886
Inventory: 494
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Shape Rectangular
Material - Magnet Nd-Fe-B
Technical
Packaging Tray
Published 2016
Series SP Micro Speaker
Size / Dimension 0.630Lx0.354W 16.00mmx9.00mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Spring Type
Type General Purpose
Power Rating 500mW
Max Power Dissipation 700mW
Technology Magnetic
Impedance 8Ohms
Frequency - Self Resonant 850Hz
Power - Max 700mW
Frequency Range 200Hz~3.4kHz
Power - Rated 500mW
Port Location Top
Efficiency - dBA 82.00
Efficiency - Type Sound Pressure Level (SPL)
Efficiency - Testing 100mW
Dimensions
Height 4.4mm
Height Seated (Max) 0.217 5.50mm
Length 16mm
Width 9mm
Compliance
RoHS Status ROHS3 Compliant
