AS10004PS-R
RoHS
/
Package /
Category Audio Products / Speakers
Description
SPEAKER 4OHM 20W TOP PORT 86DB
PDF
/
Buying Options
Total Price: USD $10
Unit Price: USD $10.004298
≥1 USD $10.004298
≥210 USD $3.992529
≥510 USD $3.858613
≥990 USD $3.792968
Inventory: 3470
Minimum: 1
-
+
Technical Details
Physical
Shape Round, Square Frame
Material - Cone Paper
Material - Magnet Ferrite
Technical
Packaging Bulk
Published 2010
Series AS
Size / Dimension 4.134Lx4.134W 105.00mmx105.00mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder Eyelet(s)
Type General Purpose
Resistance 4Ohm
Power Rating 20W
Max Power Dissipation 30W
Technology Magnetic
Impedance 4Ohms
Frequency - Self Resonant 90Hz
Power - Max 30W
Frequency Range 90Hz~10kHz
Power - Rated 20W
Port Location Top
Efficiency - dBA 86.00
Efficiency - Type Sound Pressure Level (SPL)
Efficiency - Testing 1W/1M
Dimensions
Height 59mm
Height Seated (Max) 2.283 58.00mm
Length 105mm
Width 105mm
Compliance
RoHS Status RoHS Compliant
