AS05008PR-R
RoHS
RoHS compliant
RoHS compliantPackage /
Category Audio Products / Speakers
Description
SPEAKER 8OHM 500MW TOP PORT 84DB
PDF
/
Buying Options
Total Price: USD $3.39
Unit Price: USD $3.388
≥1 USD $3.388
≥10 USD $2.80192
≥100 USD $2.58544
≥500 USD $2.428096
≥1000 USD $2.276824
≥3000 USD $2.115344
Inventory: 91
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Mount Base
Housing Material Metal
Shape Round
Material - Cone Paper
Material - Magnet Nd-Fe-B
Technical
Packaging Tray
Published 2011
Series AS
Size / Dimension 1.969Dia 50.00mm
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder Eyelet(s)
Type General Purpose
Max Operating Temperature 60°C
Min Operating Temperature -20°C
Power Rating 500mW
Max Power Dissipation 800mW
Technology Magnetic
Depth 9.5mm
Frequency 500Hz
Impedance 8Ohms
Frequency - Self Resonant 500Hz
Power - Max 200mW
Frequency Range 500Hz~4.5kHz
Power - Rated 100mW
Port Location Top
Efficiency - dBA 81.00
Efficiency - Type Sound Pressure Level (SPL)
Efficiency - Testing 100mW/500mm
Dimensions
Diameter 50mm
Height 9.5mm
Height Seated (Max) 0.394 10.00mm
Length 50mm
Compliance
RoHS Status ROHS3 Compliant
