AS04008PS-2-R
RoHS
/
Package /
Category Audio Products / Speakers
Description
SPEAKER 8OHM 200MW TOP PORT 90DB
PDF
/
Buying Options
Total Price: USD $4.54
Unit Price: USD $4.543947
≥1 USD $4.543947
≥200 USD $1.813115
≥500 USD $1.752722
≥1000 USD $1.722525
Inventory: 7240
Minimum: 1
-
+
Technical Details
Physical
Shape Round, Square Frame
Material - Cone Paper
Material - Magnet Nd-Fe-B
Technical
Packaging Tray
Published 2010
Series AS
Size / Dimension 1.594Lx1.594W 40.50mmx40.50mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder Eyelet(s)
Type General Purpose
Resistance 8Ohm
Power Rating 200mW
Max Power Dissipation 400mW
Technology Magnetic
Depth 16.7mm
Frequency 530Hz
Impedance 8Ohms
Frequency - Self Resonant 530Hz
Power - Max 400mW
Frequency Range 530Hz~8kHz
Power - Rated 200mW
Port Location Top
Efficiency - dBA 90.00
Efficiency - Type Sound Pressure Level (SPL)
Efficiency - Testing 100mW/100mm
Dimensions
Height 17mm
Height Seated (Max) 0.657 16.70mm
Length 40.5mm
Width 40.5mm
Compliance
RoHS Status RoHS Compliant
