AS03908AS-R
RoHS
RoHS compliant
RoHS compliantPackage /
Category Audio Products / Speakers
Description
SPEAKER 8OHM 5W TOP PORT 78DB
PDF
/
Buying Options
Total Price: USD $7.97
Unit Price: USD $7.96799
≥1 USD $7.96799
Inventory: 966
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Shape Round, Square Frame
Material - Cone Aluminum (AI)
Material - Magnet Nd-Fe-B
Technical
Packaging Tray
Published 2016
Series AS
Size / Dimension 1.535Lx1.535W 39.00mmx39.00mm
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Quick Connect
Type General Purpose
Power Rating 5W
Max Power Dissipation 8W
Technology Magnetic
Impedance 8Ohms
Frequency - Self Resonant 250Hz
Power - Max 8W
Frequency Range 130Hz~20kHz
Power - Rated 5W
Port Location Top
Efficiency - dBA 78.00
Efficiency - Type Sound Pressure Level (SPL)
Efficiency - Testing 1W/500mm
Dimensions
Height 29.5mm
Height Seated (Max) 0.866 22.00mm
Length 39mm
Width 39mm
Compliance
RoHS Status ROHS3 Compliant
