HDS-P830875
RoHS
RoHS compliant
RoHS compliantPackage /
Category Audio Products / Speakers
Description
SPEAKER 8OHM 75W TOP PORT 88.6DB
PDF
/
Buying Options
Total Price: USD $117.48
Unit Price: USD $117.475666
≥1 USD $117.475666
≥204 USD $46.874469
≥504 USD $45.308179
≥996 USD $44.533568
Inventory: 7321
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Seated (Max) 3.429 87.09mm
Technical
Efficiency - Testing 1W/1M
Efficiency - Type Half Space Sensitivity
Efficiency - dBA 88.60
Port Location Top
Power - Rated 75W
Frequency Range 40Hz~3kHz
Frequency - Self Resonant 45.82Hz
Impedance 7.18Ohms
Technology Magnetic
Type Woofer
Termination Solder Eyelet(s)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 6.693Dia 170.00mm
Series HDS
Published 2017
Packaging Bulk
Physical
Material - Magnet Ferrite
Material - Cone Meta-Aramid
Shape Round
Supply Chain
Factory Lead Time 18 Weeks
