BC25SC55-04
RoHS
RoHS compliant
RoHS compliantPackage /
Category Audio Products / Speakers
Description
TWEETR 4OHM 100W TOP PORT 89.6DB
PDF
/
Buying Options
Total Price: USD $34.19
Unit Price: USD $34.190542
≥1 USD $34.190542
≥240 USD $13.642344
≥480 USD $13.186768
≥960 USD $12.960949
Inventory: 918
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Shape Round, Square Frame
Material - Cone Cloth
Material - Magnet Nd-Fe-B
Technical
Packaging Bulk
Series BC
Size / Dimension 2.756Lx2.756W 70.00mmx70.00mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder Eyelet(s)
Type Tweeter
Technology Magnetic
Impedance 3.36Ohms
Frequency - Self Resonant 1401.51Hz
Frequency Range 1.4kHz~20kHz
Power - Rated 100W
Port Location Top
Efficiency - dBA 89.60
Efficiency - Type Half Space Sensitivity
Efficiency - Testing 1W/1M
Dimensions
Height Seated (Max) 1.163 29.55mm
Compliance
RoHS Status RoHS Compliant
