GF0571M
RoHS
RoHS compliant
RoHS compliantPackage /
Category Audio Products / Speakers
Description
SPEAKER 8OHM 250MW TOP PORT 86DB
PDF
/
Buying Options
Total Price: USD $6.47
Unit Price: USD $6.47391
≥1 USD $6.47391
≥200 USD $2.583787
≥500 USD $2.497136
≥1000 USD $2.455123
Inventory: 1495
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Housing Material Metal
Weight 16.4g
Shape Round
Material - Cone Polyester, Polyethylene Terephthalate (PET)
Material - Magnet Ferrite
Technical
Packaging Tray
Published 2011
Series GF
Size / Dimension 2.244Dia 57.00mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder Eyelet(s)
Type General Purpose
Resistance 8Ohm
Power Rating 250mW
Max Power Dissipation 500mW
Technology Magnetic
Impedance 8Ohm
Frequency - Self Resonant 480Hz
Frequency Range 480Hz~14kHz
Power - Rated 250mW
Port Location Top
Efficiency - dBA 86.00
Efficiency - Type Sound Pressure Level (SPL)
Efficiency - Testing 250mW/500mm
Dimensions
Height 19mm
Height Seated (Max) 0.728 18.50mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
