CMS-160916-30-2
RoHS
/
Package /
Category Audio Products / Speakers
Description
SPEAKER 6OHM 700MW TOP PORT
PDF
/
Buying Options
Total Price: USD $5.04
Unit Price: USD $5.03891
≥1 USD $5.03891
≥200 USD $2.011363
≥500 USD $1.943092
≥1000 USD $1.91027
Inventory: 6933
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Height Seated (Max) 0.130 3.30mm
Technical
Efficiency - Testing 700mW/100mm
Efficiency - Type Sound Pressure Level (SPL)
Efficiency - dBA 89.50
Port Location Top
Power - Rated 700mW
Frequency Range 440Hz~20kHz
Power - Max 1W
Frequency - Self Resonant 550Hz
Impedance 6Ohms
Technology Magnetic
Type General Purpose
Termination Spring Type
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Size / Dimension 0.630Lx0.354W 16.00mmx9.00mm
Series CMS
Published 2017
Packaging Tray
Physical
Material - Magnet Nd-Fe-B
Material - Cone Polyester, Polyethylene Terephthalate (PET)
Shape Rectangular
Supply Chain
Factory Lead Time 11 Weeks
