CLS0231MA-1-L152
RoHS
RoHS compliant
RoHS compliantPackage /
Category Audio Products / Speakers
Description
SPEAKER 8OHM 500MW TOP PORT 89DB
PDF
/
Buying Options
Total Price: USD $3.65
Unit Price: USD $3.652
≥1 USD $3.652
≥10 USD $3.02104
≥100 USD $2.78784
≥500 USD $2.618
≥1000 USD $2.455006
≥3000 USD $2.280846
Inventory: 1105
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Shape Round
Material - Cone Polyester, Polyethylene Terephthalate (PET)
Material - Magnet Nd-Fe-B
Technical
Packaging Tray
Published 2011
Series CLS
Size / Dimension 0.906Dia 23.00mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Wire Leads
Type Low Profile
Resistance 8Ohm
Power Rating 500mW
Max Power Dissipation 1W
Technology Magnetic
Impedance 8Ohms
Frequency - Self Resonant 670Hz
Power - Max 1W
Frequency Range 536Hz~20kHz
Power - Rated 500mW
Port Location Top
Efficiency - dBA 89.00
Efficiency - Type Sound Pressure Level (SPL)
Efficiency - Testing 1W/500mm
Dimensions
Height 5.3mm
Height Seated (Max) 0.197 5.00mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
