CDS-25148-L100
RoHS
RoHS compliant
RoHS compliantPackage /
Category Audio Products / Speakers
Description
SPEAKER 8OHM 1.5W TOP PORT 94DB
PDF
/
Buying Options
Total Price: USD $3.12
Unit Price: USD $3.1152
≥1 USD $3.1152
≥10 USD $2.5784
≥100 USD $2.378816
≥500 USD $2.2341
≥1000 USD $2.094928
≥3000 USD $1.946322
Inventory: 1233
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Height Seated (Max) 0.177 4.50mm
Height 4.5mm
Technical
Efficiency - Testing 1W/1M
Efficiency - Type Sound Pressure Level (SPL)
Efficiency - dBA 73.00
Port Location Top
Power - Rated 1.5W
Frequency Range 600Hz~20kHz
Frequency - Self Resonant 750Hz
Impedance 8Ohm
Technology Magnetic
Max Power Dissipation 2W
Power Rating 1.5W
Type General Purpose
Termination Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.984Lx0.551W 25.00mmx14.00mm
Series CDS
Published 2016
Packaging Tray
Physical
Material - Magnet Nd-Fe-B
Material - Cone Cloth
Shape Rectangular
Supply Chain
Factory Lead Time 14 Weeks
