LH1512BAC
RoHS
RoHS compliant
RoHS compliantPackage 8-SMD (0.300, 7.62mm)
Category Relays / Solid State Relays
Description
Relay SSR 50mA 1.45V DC-IN 0.2A 200V AC/DC-OUT 8-Pin PDIP SMD Tube
PDF
/
Buying Options
Total Price: USD $4.93
Unit Price: USD $4.928
≥1 USD $4.928
≥10 USD $4.61912
≥100 USD $4.106432
≥500 USD $3.900864
≥1000 USD $3.695648
≥3000 USD $3.285005
Inventory: 537
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SMD (0.300, 7.62mm)
Number of Pins 8
Technical
Packaging Tube
Series LH1512
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Gull Wing
ECCN Code EAR99
Resistance 10Ohm
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Additional Feature UL RECOGNIZED
Termination Style Gull Wing
Output Type AC, DC
Max Output Current 200mA
Operating Supply Voltage 200V
Number of Elements 2
Circuit SPST-NO + SPST-NC (1 Form A and B)
Voltage - Input 1.26VDC
Output Current 200mA
Throw Configuration DPST, SPST
Input Type DC
Optoelectronic Device Type TRANSISTOR OUTPUT SSR
Max Output Voltage 200V
Max Input Voltage 1.45V
Relay Type Relay
Voltage - Load 0V~200V
Forward Current-Max 0.05A
On-State Resistance (Max) 10Ohm
Max Input Current 50mA
Overall Height 3.3mm
Input Current 50mA
On-State Current-Max 0.2A
Isolation Voltage 3.75kV
Overall Length 9.65mm
Control Current 0.0006A
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
