LH1511BABTR
RoHS
RoHS compliant
RoHS compliantPackage 6-SMD (0.300, 7.62mm)
Category Relays / Solid State Relays
Description
Solid State Relays - PCB Mount Normally Closed Form 1B 200V
PDF
/
Buying Options
Total Price: USD $3.94
Unit Price: USD $3.9424
≥1 USD $3.9424
≥10 USD $3.69952
≥100 USD $3.288384
≥500 USD $3.124176
≥1000 USD $2.959704
≥3000 USD $2.630848
Inventory: 1000
Minimum: 1
-
+
Technical Details
Physical
Package / Case 6-SMD (0.300, 7.62mm)
Number of Pins 6
Mounting Type Surface Mount
Mount Surface Mount
Technical
Packaging Tape & Reel (TR)
Series LH1511
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Gull Wing
ECCN Code EAR99
Resistance 10Ohm
Max Operating Temperature 85°C
Min Operating Temperature -40°C
HTS Code 8541.40.95.00
Termination Style Gull Wing
Output Type AC, DC
Max Output Current 300mA
Number of Elements 1
Circuit SPST-NC (1 Form B)
Voltage - Input 1.26VDC
Output Current 300mA
Throw Configuration SPST
Input Type DC
Optoelectronic Device Type TRANSISTOR OUTPUT SSR
Max Output Voltage 200V
Max Input Voltage 1.45V
Relay Type Relay
Voltage - Load 0V~200V
Forward Current-Max 0.05A
On-State Resistance (Max) 10Ohm
Max Input Current 50mA
Overall Height 3.3mm
Input Current 50mA
On-State Current-Max 0.2A
Load Current 200mA
Isolation Voltage 3.75kV
Control Current 0.0002A
Supply Chain
Factory Lead Time 13 Weeks
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
