TLP176AM(TPL,E
RoHS
RoHS compliant
RoHS compliantPackage 6-SOP (0.179, 4.55mm), 4 Leads
Category Relays / Solid State Relays
Description
SSR RELAY SPST-NO 700MA 0-60V
PDF
/
Buying Options
Total Price: USD $1.21
Unit Price: USD $1.2144
≥1 USD $1.2144
≥10 USD $1.1396
≥100 USD $1.013056
≥500 USD $0.962544
≥1000 USD $0.911944
≥3000 USD $0.810586
Inventory: 1115
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Isolation Voltage-Max 3750V
Load Current 700mA
On-State Resistance (Max) 2Ohm
Forward Current-Max 0.0195A
Voltage - Load 0V~60V
Optoelectronic Device Type TRANSISTOR OUTPUT SSR
Voltage - Input 1.27VDC
Configuration SINGLE WITH BUILT-IN DIODE
Circuit SPST-NO (1 Form A)
Number of Elements 1
Output Type AC, DC
Operating Temperature (Min) -20°C
Operating Temperature (Max) 85°C
Termination Style Gull Wing
Additional Feature UL APPROVED
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series TLP176AM
Published 2018
Packaging Tape & Reel (TR)
Physical
Package / Case 6-SOP (0.179, 4.55mm), 4 Leads
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
