SSRT-240D25 image
Favorite
RoHS
RoHS RoHS compliant
Package Hockey Puck
Category Relays / Solid State Relays
Description SSR RELAY SPST-NO 25A 24-280V
PDF
/
Buying Options
Total Price: USD $42.32
Unit Price: USD $42.3192
≥1 USD $42.3192
≥10 USD $40.09368
≥100 USD $39.214912
Inventory: 381
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Not Applicable
RoHS Status RoHS Compliant
REACH SVHC Unknown

Dimensions

Length 57.15mm
Height 22.1mm

Technical

Nominal Input Voltage (DC) 32V
Control Voltage 3V
Input Current 25A
Max Input Current 14mA
Voltage - Load 24V~280V
Relay Type Relay
Contact Current Rating 25A
Max Output Voltage 280V
Turn On Delay Time 8.3 ms
Input Type DC
Max Voltage Rating (DC) 32V
Throw Configuration SPST
Output Current 25A
Voltage - Input 3V~32VDC
ELV Compliant
Circuit SPST-NO (1 Form A)
Operating Supply Voltage 280V
Output Type AC, Zero Cross
Approval Agency cULus
Voltage - Rated AC 280V
Termination Style Screw Terminal
Current Rating 25A
Depth 44.45mm
Min Operating Temperature -20°C
Max Operating Temperature 80°C
Termination Screw
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series SSRT
Published 2003
Packaging Bulk

Physical

Number of Pins 4
Package / Case Hockey Puck
Mounting Type Chassis Mount
Mount Chassis Mount

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 17 Weeks
