S116S02F
RoHS
/
Package 4-SIP
Category Relays / Solid State Relays
Description
SSR RELAY SPST-NO 16A 80-120V
PDF
/
Buying Options
Total Price: USD $9.4
Unit Price: USD $9.3974
≥1 USD $9.3974
≥10 USD $7.7102
≥100 USD $7.46985
≥500 USD $7.22855
≥1000 USD $6.9882
Inventory: 10905
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 4-SIP
Number of Pins 4
Technical
Packaging Bulk
Published 2004
Series S116
JESD-609 Code e2
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Terminal Finish Tin/Copper (Sn/Cu)
Max Operating Temperature 100°C
Min Operating Temperature -25°C
Additional Feature UL RECOGNIZED, HIGH RELIABILITY, WITH ZERO CROSSOVER CIRCUIT
Termination Style PC Pin
Output Type AC, Zero Cross
Max Output Current 16A
Number of Elements 1
Circuit SPST-NO (1 Form A)
Voltage - Input 1.2VDC
Output Current 16A
Throw Configuration SPST
Optoelectronic Device Type TRIGGER OUTPUT SSR
Max Output Voltage 400V
Max Input Voltage 1.4V
Relay Type Relay
Voltage - Load 80V~120V
Forward Current-Max 0.05A
Max Input Current 50mA
Input Current 100μA
Isolation Voltage 4kV
Dimensions
Height 24.6mm
Length 18.5mm
Width 5.5mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
