S101S05V
RoHS
/
Package 4-SIP
Category Relays / Solid State Relays
Description
RELAY SSR 120VAC 3A TRIAC 4-SIP
PDF
/
Buying Options
Total Price: USD $6.56
Unit Price: USD $6.563187
≥1 USD $6.563187
≥200 USD $2.619236
≥500 USD $2.531271
≥1000 USD $2.487946
Inventory: 7765
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 4-SIP
Number of Pins 4
Technical
Packaging Tube
Published 2004
Series S101
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Terminal Finish Tin/Lead (Sn/Pb)
Max Operating Temperature 100°C
Min Operating Temperature -25°C
Additional Feature UL RECOGNIZED, HIGH RELIABILITY
Termination Style PC Pin
Output Type AC
Number of Elements 1
Circuit SPST-NO (1 Form A)
Voltage - Input 1.2VDC
Output Current 3A
Throw Configuration SPST
Optoelectronic Device Type TRIGGER OUTPUT SSR
Max Output Voltage 400V
Relay Type Relay
Voltage - Load 80V~120V
Forward Current-Max 0.05A
Input Current 50mA
On-State Current-Max 3A
Isolation Voltage 3kV
Dimensions
Height 24.6mm
Length 18.5mm
Width 5.5mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
