PR36MF11NSZF
RoHS
/
Package 8-DIP (0.300, 7.62mm), 7 Leads
Category Relays / Solid State Relays
Description
RELAY SSR 240VAC .6A TRIAC 8-DIP
PDF
/
Buying Options
Total Price: USD $1.48
Unit Price: USD $1.477013
≥1 USD $1.477013
≥200 USD $0.589492
≥500 USD $0.569799
≥1000 USD $0.560608
Inventory: 7708
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 8-DIP (0.300, 7.62mm), 7 Leads
Technical
Packaging Tube
Published 1997
Series PR36MF
JESD-609 Code e2
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Terminal Finish Tin/Copper (Sn/Cu)
Additional Feature UL RECOGNIZED, HIGH RELIABILITY
Reach Compliance Code unknown
Termination Style PC Pin
Operating Temperature (Max) 85°C
Operating Temperature (Min) -25°C
Output Type AC
Number of Elements 1
Circuit SPST-NO (1 Form A)
Voltage - Input 1.2VDC
Throw Configuration DPDT, SPST
Optoelectronic Device Type TRIGGER OUTPUT SSR
Relay Type Relay
Voltage - Load 0V~240V
Forward Current-Max 0.05A
Input Current 100μA
On-State Current-Max 0.6A
Load Current 600mA
Isolation Voltage-Max 4000V
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
