PR26MF11NSZF
RoHS
/
Package 8-DIP (0.300, 7.62mm), 7 Leads
Category Relays / Solid State Relays
Description
RELAY SSR 120VAC .6A TRIAC 8-DIP
PDF
/
Buying Options
Total Price: USD $0.5
Unit Price: USD $0.4978
≥1 USD $0.4978
≥10 USD $0.4085
≥100 USD $0.39615
≥500 USD $0.38285
≥1000 USD $0.3705
Inventory: 1514
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 8-DIP (0.300, 7.62mm), 7 Leads
Number of Pins 8
Technical
Packaging Tube
Published 2004
Series PR26MF
JESD-609 Code e2
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Terminal Finish Tin/Copper (Sn/Cu)
Max Operating Temperature 85°C
Min Operating Temperature -25°C
Additional Feature UL RECOGNIZED, HIGH RELIABILITY
Termination Style PC Pin
Output Type AC
Number of Elements 1
Circuit SPST-NO (1 Form A)
Voltage - Input 1.2VDC
Output Current 600mA
Throw Configuration SPST
Optoelectronic Device Type TRIGGER OUTPUT SSR
Max Output Voltage 400V
Max Input Voltage 1.4V
Relay Type Relay
Voltage - Load 0V~120V
Forward Current-Max 0.05A
Max Input Current 50mA
Input Current 100μA
On-State Current-Max 0.6A
Isolation Voltage 4kV
Dimensions
Height 3.5mm
Length 9.66mm
Width 6.5mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
