LVD75F60H

Sensata-Crydom
RoHS
RoHS RoHS compliant
Package Hockey Puck
Category Relays / Solid State Relays
Description DC RoHS Compliant Active SPST Solid State Relay 80C 25.6V~26.6VDC 22.9mm 60A
PDF
/
Buying Options
Total Price: USD $425.52
Unit Price: USD $425.518767
≥1 USD $425.518767
≥200 USD $169.785541
≥500 USD $164.111187
≥1000 USD $161.308146
Inventory: 2232
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Length 58.4mm
Height 22.9mm

Technical

Isolation Voltage 2.5kV
Load Current 60A
Input Current 12mA
Max Input Current 12mA
On-State Resistance (Max) 10mOhms
Voltage - Load 3V~75V
Relay Type Relay
Max Output Voltage 75V
Throw Configuration SPST
Output Current 60A
Voltage - Input 25.6V~26.6VDC
Circuit SPST-NO (1 Form A)
Operating Supply Voltage 75V
Max Output Current 60A
Output Type DC
Termination Style Screw Terminal
Current Rating 60A
Min Operating Temperature -30°C
Max Operating Temperature 80°C
Resistance 10mOhm
Termination Screw
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series LVD
Published 2010
Packaging Bulk

Physical

Weight 99.999994g
Number of Pins 4
Package / Case Hockey Puck
Mounting Type Chassis Mount
Mount Chassis Mount, Panel, Screw

Supply Chain

Factory Lead Time 6 Weeks
