LVD75D60H
RoHS
RoHS compliant
RoHS compliantPackage Hockey Puck
Category Relays / Solid State Relays
Description
SSR, 48V/60A, 24/23.5VCTRL, LVD W/PAD
PDF
/
Buying Options
Total Price: USD $131.51
Unit Price: USD $131.513489
≥1 USD $131.513489
≥10 USD $124.069335
≥100 USD $117.046538
≥500 USD $110.421262
≥1000 USD $104.171003
Inventory: 1395
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Technical
Min Supply Voltage (DC) 3V
Isolation Voltage 2.5kV
Max Supply Voltage (DC) 75V
Load Current 60A
Max Input Current 12mA
On-State Resistance (Max) 10mOhms
Voltage - Load 3V~75V
Relay Type Relay
Max Output Voltage 75V
Max Voltage Rating (DC) 75V
Throw Configuration SPST
Voltage - Input 23V~24VDC
Circuit SPST-NO (1 Form A)
Operating Supply Voltage 75V
Max Output Current 60A
Output Type DC
Termination Style Screw Terminal
Current Rating 60A
Min Operating Temperature -30°C
Max Operating Temperature 80°C
Resistance 10mOhm
Termination Screw
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series LVD
Published 2010
Packaging Bulk
Physical
Weight 99.999994g
Number of Pins 4
Package / Case Hockey Puck
Mounting Type Chassis Mount
Mount Chassis Mount, Panel, Screw
Supply Chain
Factory Lead Time 6 Weeks
