LVD75C100
RoHS
RoHS compliant
RoHS compliantPackage Hockey Puck
Category Relays / Solid State Relays
Description
RELAY SSR LOWVOL DIS 12.5V 100A
PDF
/
Buying Options
Total Price: USD $262.77
Unit Price: USD $262.765119
≥1 USD $262.765119
≥200 USD $101.686731
≥500 USD $98.113017
≥1000 USD $96.347167
Inventory: 4750
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Isolation Voltage 2.5kV
Load Current 100A
Max Input Current 12mA
On-State Resistance (Max) 5mOhms
Voltage - Load 3V~75V
Relay Type Relay
Max Output Voltage 75V
Throw Configuration SPST
Voltage - Input 12V~12.5VDC
Circuit SPST-NO (1 Form A)
Operating Supply Voltage 75V
Max Output Current 100A
Output Type DC
Termination Style Screw Terminal
Current Rating 100A
Min Operating Temperature -30°C
Max Operating Temperature 80°C
Resistance 5mOhm
Termination Screw
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series LVD
Published 2010
Packaging Bulk
Physical
Weight 99.999994g
Number of Pins 4
Package / Case Hockey Puck
Mounting Type Chassis Mount
Mount Chassis Mount, Panel, Screw
Supply Chain
Factory Lead Time 6 Weeks
