LVD75B60

Sensata-Crydom
RoHS
RoHS RoHS compliant
Package Hockey Puck
Category Relays / Solid State Relays
Description SSR, 48V/60A, 12/11.5VCTRL, LVD - More Details
PDF
/
Inventory: 7230
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 6 Weeks

Physical

Mount Chassis Mount, Panel, Screw
Mounting Type Chassis Mount
Package / Case Hockey Puck
Number of Pins 4
Weight 99.999994g

Technical

Packaging Bulk
Published 2010
Series LVD
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screw
Resistance 10mOhm
Max Operating Temperature 80°C
Min Operating Temperature -30°C
Current Rating 60A
Termination Style Screw Terminal
Output Type DC
Max Output Current 60A
Operating Supply Voltage 75V
Circuit SPST-NO (1 Form A)
Max Supply Voltage 75V
Min Supply Voltage 3V
Voltage - Input 11.5V~12VDC
Output Current 60A
Throw Configuration SPST
Max Output Voltage 75V
Max Surge Current 180A
Relay Type Relay
Voltage - Load 3V~75V
On-State Resistance (Max) 10mOhm
Max Input Current 12mA
Input Current 12mA
Isolation Voltage 2.5kV

Dimensions

Height 22.9mm
Length 58.4mm
Width 45.7mm

Compliance

Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
