LVD75A60H
RoHS
RoHS compliant
RoHS compliantPackage Hockey Puck
Category Relays / Solid State Relays
Description
SSR, 48V/60A, 11.5/11VCTRL, LVD W/PAD - More Details
PDF
/
Inventory: 1932
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Technical
Isolation Voltage 2.5kV
Load Current 60A
Max Input Current 12mA
On-State Resistance (Max) 10mOhms
Voltage - Load 3V~75V
Relay Type Relay
Max Surge Current 180A
Max Output Voltage 75V
Throw Configuration SPST
Voltage - Input 11V~11.5VDC
Min Supply Voltage 3V
Max Supply Voltage 75V
Circuit SPST-NO (1 Form A)
Operating Supply Voltage 75V
Max Output Current 60A
Output Type DC
Termination Style Screw Terminal
Current Rating 60A
Min Operating Temperature -30°C
Max Operating Temperature 80°C
Resistance 10mOhm
Termination Screw
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series LVD
Published 2010
Packaging Bulk
Physical
Weight 99.999994g
Number of Pins 4
Package / Case Hockey Puck
Mounting Type Chassis Mount
Mount Chassis Mount, Panel, Screw
Supply Chain
Factory Lead Time 6 Weeks
