LR600240D40
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Relays / Solid State Relays
Description
SSR RELAY SPST-NO 40A 24-280V
PDF
/
Buying Options
Total Price: USD $46.44
Unit Price: USD $46.4376
≥1 USD $46.4376
≥10 USD $44.22
≥100 USD $42.213952
≥500 USD $40.973064
Inventory: 485
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount PCB, Through Hole
Mounting Type Through Hole
Package / Case Module
Number of Pins 4
Technical
Packaging Bulk
Published 2008
Series LR
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Max Operating Temperature 80°C
Min Operating Temperature -30°C
Capacitance 8pF
Depth 28.4mm
Current Rating 40A
Termination Style PC Pin
Voltage - Rated AC 280V
Approval Agency CE, UL
Output Type AC, Zero Cross
Max Output Current 40A
Operating Supply Voltage 280V
Circuit SPST-NO (1 Form A)
Voltage - Input 4V~32VDC
Throw Configuration SPST
Max Output Voltage 280V
Relay Type Relay
Voltage - Load 24V~280V
Input Current 15mA
Load Current 40A
Dimensions
Height 6.3mm
Length 35mm
Width 28.4mm
Compliance
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
