LC241R
RoHS
/
Package 4-SIP
Category Relays / Solid State Relays
Description
SSR, MINI-SIP, 240VAC/1.5A, LVDC IN RN - More Details
PDF
/
Buying Options
Total Price: USD $79.4
Unit Price: USD $79.40385
≥1 USD $79.40385
≥10 USD $76.92245
≥100 USD $74.44105
≥500 USD $71.95965
≥1000 USD $64.51545
Inventory: 163
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 5.1mm
Length 24.1mm
Height 12.7mm
Technical
Isolation Voltage 2.5kV
Input Current 15mA
Voltage - Load 12V~280V
Relay Type Relay
Max Output Voltage 280V
Max Voltage Rating (DC) 10V
Throw Configuration SPST
Output Current 1.5A
Voltage - Input 4V~10VDC
Circuit SPST-NO (1 Form A)
Max Output Current 1.5A
Output Type AC
Output Voltage 280V
Voltage - Rated AC 240V
Termination Style PC Pin
Current Rating 1.5A
Depth 5.1mm
Min Operating Temperature -40°C
Max Operating Temperature 80°C
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series LC
Published 2008
Packaging Bulk
Physical
Number of Pins 4
Package / Case 4-SIP
Mounting Type Through Hole
Mount PCB, Panel, Through Hole
