HS501DR-HD6025
RoHS
RoHS compliant
RoHS compliantPackage Hockey Puck with Heat Sink
Category Relays / Solid State Relays
Description
AC Zero Cross General Purpose Passive RoHS Compliant Yellow Solid State Relay 3V~32VDC 26.5mm 10A
PDF
/
Buying Options
Total Price: USD $199.02
Unit Price: USD $199.02079
≥1 USD $199.02079
≥10 USD $187.755467
≥100 USD $177.127802
≥500 USD $167.101692
≥1000 USD $157.643105
Inventory: 3779
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mount DIN Rail
Mounting Type DIN Rail
Package / Case Hockey Puck with Heat Sink
Technical
Packaging Bulk
Published 2009
Series HS
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screw
Type General Purpose, Passive
Color Yellow
Depth 45.7mm
Current Rating 10A
Termination Style Screw Terminal
Approval Agency CE, CSA, UL, VDE
Output Type AC, Zero Cross
Circuit SPST-NO (1 Form A)
Voltage - Input 3V~32VDC
Throw Configuration SPST
Max Voltage Rating (DC) 32V
Max Surge Current 250A
Relay Type Relay
Voltage - Load 48V~660V
RMS Current (Irms) 10A
Dimensions
Height 26.5mm
Length 79.9mm
Width 45.7mm
Compliance
REACH SVHC No SVHC
RoHS Status RoHS Compliant
