HS103DR-D53TP25D

Sensata-Crydom
RoHS
RoHS RoHS compliant
Package Hockey Puck with Heat Sink
Category Relays / Solid State Relays
Description Solid State Relays - Industrial Mount SSR / HS Assy; Rated 18.3A 3-Pha
PDF
/
Buying Options
Total Price: USD $803.82
Unit Price: USD $803.823025
≥1 USD $803.823025
≥200 USD $320.730967
≥500 USD $310.013764
≥1000 USD $304.717526
Inventory: 8533
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Length 132.1mm
Height 99.2mm

Technical

Load Current 55A
Voltage - Load 48V~530V
Relay Type Relay
Throw Configuration SPST
Voltage - Input 3V~32VDC
Circuit SPST-NO (1 Form A)
Output Type AC, Zero Cross
Termination Style Screw Terminal
Depth 76.2mm
Min Operating Temperature -40°C
Max Operating Temperature 80°C
Type Passive
Termination Screw
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series HS
Published 2010
Packaging Bulk

Physical

Package / Case Hockey Puck with Heat Sink
Mounting Type DIN Rail
Mount DIN Rail

Supply Chain

Factory Lead Time 7 Weeks
