HD6050
RoHS
RoHS compliant
RoHS compliantPackage Hockey Puck
Category Relays / Solid State Relays
Description
SSR RELAY SPST-NO 50A 48-660V
PDF
/
Inventory: 7195
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Physical
Mount Chassis Mount, Panel, Screw
Mounting Type Chassis Mount
Package / Case Hockey Puck
Number of Pins 4
Technical
Packaging Bulk
Published 2009
Series HD60
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Screw
Max Operating Temperature 80°C
Min Operating Temperature -40°C
Max Power Dissipation 500mW
Depth 45.7mm
Current Rating 50A
Termination Style Screw Terminal
Voltage - Rated AC 660V
Approval Agency CE, CSA, UL, VDE
Output Voltage 660V
Output Type AC, Zero Cross
Max Output Current 50A
Operating Supply Voltage 660V
Circuit SPST-NO (1 Form A)
Max Supply Voltage 660V
Min Supply Voltage 48V
Voltage - Input 3V~32VDC
Output Current 50A
Throw Configuration SPST
Max Voltage Rating (DC) 32V
Max Output Voltage 660V
Relay Type Relay
Voltage - Load 48V~660V
Input Current 12mA
Load Current 50A
Isolation Voltage 4kV
Dimensions
Height 23mm
Length 58.4mm
Width 22.9mm
Compliance
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
