H12WD4890

Sensata-Crydom
RoHS
RoHS RoHS compliant
Package Hockey Puck
Category Relays / Solid State Relays
Description SSR RELAY SPST-NO 90A 48-660V
PDF
/
Buying Options
Total Price: USD $27.65
Unit Price: USD $27.64975
≥1 USD $27.64975
≥10 USD $22.68695
≥100 USD $21.97825
≥500 USD $21.2686
≥1000 USD $20.5599
Inventory: 56
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No

Dimensions

Width 45.7mm
Length 45.7mm
Height 23mm

Technical

Min Supply Voltage (AC) 48V
Max Supply Voltage (AC) 660V
Isolation Voltage 4kV
Load Current 90A
Input Current 12mA
Voltage - Load 48V~660V
Relay Type Relay
Max Surge Current 1.2kA
Max Output Voltage 660V
Throw Configuration SPST
Output Current 90A
Voltage - Input 4V~32VDC
Circuit SPST-NO (1 Form A)
Operating Supply Voltage 660V
Max Output Current 90A
Output Type AC, Zero Cross
Output Voltage 660V
Approval Agency CE, CSA, UL, VDE
Voltage - Rated AC 660V
Termination Style Screw Terminal
Current Rating 90A
Depth 45.7mm
Max Power Dissipation 500mW
Min Operating Temperature -40°C
Max Operating Temperature 80°C
Resistance 1.5kOhm
Termination Screw
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series H12WD
Published 2000
Packaging Bulk

Physical

Number of Pins 4
Package / Case Hockey Puck
Mounting Type Chassis Mount
Mount Chassis Mount, Panel, Screw

Supply Chain

Factory Lead Time 6 Weeks
