H12WD4850
RoHS
RoHS compliant
RoHS compliantPackage Hockey Puck
Category Relays / Solid State Relays
Description
SSR, PANEL MOUNT, 660VAC, 32VDC, 50A
PDF
/
Buying Options
Total Price: USD $68.45
Unit Price: USD $68.448845
≥1 USD $68.448845
≥10 USD $64.574385
≥100 USD $60.919227
≥500 USD $57.47097
≥1000 USD $54.217904
Inventory: 1506
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Chassis Mount, Panel, Screw
Mounting Type Chassis Mount
Package / Case Hockey Puck
Number of Pins 4
Technical
Packaging Bulk
Published 2001
Series H12WD
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Screw
Resistance 1.5kOhm
Max Operating Temperature 80°C
Min Operating Temperature -40°C
Depth 45.7mm
Current Rating 50A
Termination Style Screw Terminal
Voltage - Rated AC 660V
Approval Agency CE, CSA, UL, VDE
Output Voltage 660V
Output Type AC, Zero Cross
Max Output Current 50A
Operating Supply Voltage 660V
Circuit SPST-NO (1 Form A)
Voltage - Input 4V~32VDC
Output Current 50A
Throw Configuration SPST
Max Output Voltage 660V
Max Surge Current 625A
Relay Type Relay
Voltage - Load 48V~660V
Input Current 15mA
Load Current 50A
Isolation Voltage 4kV
Max Supply Voltage (AC) 660V
Min Supply Voltage (AC) 48V
Dimensions
Height 23mm
Length 58.4mm
Width 45.7mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
