G2-DB01-TT

Sensata-Crydom
RoHS
/
Package 8-DIP (0.300, 7.62mm)
Category Relays / Solid State Relays
Description SSR RELAY SPST-NC 170MA 0-350V
PDF
/
Buying Options
Total Price: USD $76.77
Unit Price: USD $76.7695
≥1 USD $76.7695
≥10 USD $74.3698
≥100 USD $71.97105
≥500 USD $69.5723
≥1000 USD $62.3751
Inventory: 1709
Minimum: 1
-
+

Technical Details

Physical

Mount Through Hole
Mounting Type Through Hole
Package / Case 8-DIP (0.300, 7.62mm)
Number of Pins 8
Supplier Device Package 8-DIP

Technical

Packaging Tube
Published 2002
Series G2
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Resistance 20Ohm
Termination Style PC Pin
Output Type AC, DC
Max Output Current 120mA
Circuit SPST-NC (1 Form B) x 2
Voltage - Input 1.2VDC
Throw Configuration DPST
Max Output Voltage 350V
Relay Type Relay
Voltage - Load 0V~350V
On-State Resistance (Max) 20Ohms
Max Input Current 50mA
Load Current 170mA

Compliance

RoHS Status RoHS Compliant
Lead Free Lead Free
