EL240A10R-24

Sensata-Crydom
RoHS
RoHS RoHS compliant
Package Module
Category Relays / Solid State Relays
Description SSR RELAY SPST-NO 10A 24-280V
PDF
/
Buying Options
Total Price: USD $82.07
Unit Price: USD $82.070692
≥1 USD $82.070692
≥200 USD $32.747665
≥500 USD $31.652706
≥1000 USD $31.111791
Inventory: 2631
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 6 Weeks

Physical

Mount Chassis Mount, Panel, Screw
Mounting Type Chassis Mount
Package / Case Module
Number of Pins 4
Weight 14.399999g

Technical

Packaging Bulk
Published 2011
Series EL
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Quick Connect
Max Operating Temperature 80°C
Min Operating Temperature -30°C
Depth 21.1mm
Current Rating 10A
Termination Style Quick Connect - 0.187/0.250
Output Type AC
Circuit SPST-NO (1 Form A)
Max Voltage Rating (AC) 280V
Voltage - Input 21V~27VDC
Throw Configuration SPST
Turn On Delay Time 20 μs
Max Output Voltage 280V
Relay Type Relay
Voltage - Load 24V~280V
Input Current 5.9mA
Load Current 10A
Isolation Voltage 3.75kV
Max Supply Voltage (AC) 280V
Min Supply Voltage (AC) 24V

Dimensions

Height 14.3mm
Length 35.6mm

Compliance

Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
