DC60SA7 image
Favorite
DC60SA7 image
Favorite
RoHS
/
Package Hockey Puck
Category Relays / Solid State Relays
Description SSR RELAY SPST-NO 7A 3-60V
PDF
/
Inventory: 1700
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No

Dimensions

Width 45.7mm
Length 45.7mm
Height 58.4mm

Technical

Isolation Voltage 4kV
Input Current 4mA
RMS Current (Irms) 7A
Voltage - Load 3V~60V
Turn-Off Delay Time 40 ms
Relay Type Relay
Max Surge Current 14A
Max Output Voltage 60V
Turn On Delay Time 10 ms
Throw Configuration SPST
Output Current 7A
Voltage - Input 90V~280VAC
Min Supply Voltage 3V
Max Supply Voltage 60V
Leakage Current 100μA
Insulation Resistance 1GOhm
Circuit SPST-NO (1 Form A)
Operating Supply Voltage 60V
Max Output Current 7A
Output Type DC
Output Voltage 60V
Approval Agency CE, CSA, UL
Termination Style Screw Terminal
Current Rating 7A
Depth 19.8mm
Voltage - Rated DC 60V
Min Operating Temperature -30°C
Max Operating Temperature 80°C
Termination Screw
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Series DC60
Published 2008
Packaging Bulk

Physical

Number of Pins 4
Package / Case Hockey Puck
Mounting Type Chassis Mount
Mount Chassis Mount, Panel, Screw, Surface Mount
