D1D07L
RoHS
RoHS compliant
RoHS compliantPackage Hockey Puck
Category Relays / Solid State Relays
Description
Relay SSR 10.6mA 32V DC-IN 7A 100V DC-OUT 4-Pin
PDF
/
Buying Options
Total Price: USD $231.3
Unit Price: USD $231.295384
≥1 USD $231.295384
≥10 USD $218.203185
≥100 USD $205.852061
≥500 USD $194.200063
≥1000 USD $183.207598
Inventory: 8064
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No
Technical
Min Supply Voltage (DC) 0V
Isolation Voltage 2.5kV
Max Supply Voltage (DC) 100V
Input Current 10mA
Max Input Current 10.6mA
On-State Resistance (Max) 290mOhm
Voltage - Load 0V~100V
Relay Type Relay
Max Output Voltage 100V
Max Voltage Rating (DC) 100V
Throw Configuration SPST
Output Current 7A
Voltage - Input 3.5V~32VDC
Circuit SPST-NO (1 Form A)
Operating Supply Voltage 100V
Max Output Current 7A
Output Type DC
Termination Style Screw Terminal
Min Operating Temperature -40°C
Max Operating Temperature 80°C
Resistance 290mOhm
Termination Screw
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Not For New Designs
Series 1-DCL
Published 2009
Packaging Bulk
Physical
Number of Pins 4
Package / Case Hockey Puck
Mounting Type Chassis Mount
Mount Chassis Mount, Panel, Screw
Supply Chain
Factory Lead Time 3 Weeks
