CWD4890P
RoHS
RoHS compliant
RoHS compliantPackage Hockey Puck
Category Relays / Solid State Relays
Description
SSR RELAY SPST-NO 90A 48-660V
PDF
/
Buying Options
Total Price: USD $127.8
Unit Price: USD $127.8024
≥1 USD $127.8024
≥10 USD $121.72248
≥100 USD $116.186576
Inventory: 112
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Physical
Contact Material Silver
Mount Chassis Mount, Panel, Screw
Mounting Type Chassis Mount
Package / Case Hockey Puck
Number of Pins 4
Technical
Packaging Bulk
Published 2008
Series CW48
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Screw
Max Operating Temperature 80°C
Min Operating Temperature -40°C
Depth 33mm
Current Rating 90A
Termination Style Screw Terminal
Voltage - Rated AC 660V
Approval Agency CE, CSA, UL, VDE
Output Type AC, Zero Cross
Operating Supply Voltage 660V
Circuit SPST-NO (1 Form A)
Insulation Resistance 1GOhm
Leakage Current 1mA
Max Supply Voltage 280V
Min Supply Voltage 12V
Voltage - Input 4V~32VDC
Output Current 90A
Throw Configuration SPST
Max Output Voltage 660V
Max Surge Current 1.35kA
Relay Type Relay
Voltage - Load 48V~660V
RMS Current (Irms) 90A
Input Current 10mA
Load Current 90A
Isolation Voltage 4kV
Dimensions
Height 58.4mm
Length 25.4mm
Width 45.7mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
