CWD4850 image
Favorite
CWD4850 image
Favorite
RoHS
RoHS RoHS compliant
Package Hockey Puck
Category Relays / Solid State Relays
Description SSR RELAY SPST-NO 50A 48-660V
PDF
/
Buying Options
Total Price: USD $572.24
Unit Price: USD $572.23535
≥1 USD $572.23535
Inventory: 204
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 5 Weeks

Physical

Contact Material Silver
Mount Chassis Mount, Panel, Screw
Mounting Type Chassis Mount
Package / Case Hockey Puck
Number of Pins 4

Technical

Packaging Bulk
Published 2004
Series CW48
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Screw
Max Operating Temperature 80°C
Min Operating Temperature -40°C
Depth 58.4mm
Current Rating 50A
Termination Style Screw Terminal
Voltage - Rated AC 660V
Approval Agency CE, CSA, UL, VDE
Output Voltage 660V
Output Type AC, Zero Cross
Operating Supply Voltage 660V
Circuit SPST-NO (1 Form A)
Insulation Resistance 1GOhm
Voltage - Input 4V~32VDC
Output Current 50A
Throw Configuration SPST
Max Output Voltage 660V
Max Surge Current 850A
Relay Type Relay
Voltage - Load 48V~660V
Input Current 10mA
Load Current 50A
Isolation Voltage 4kV

Dimensions

Height 33mm
Length 58.4mm
Width 45.7mm

Compliance

Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
