CWD2425-10
RoHS
RoHS compliant
RoHS compliantPackage Hockey Puck
Category Relays / Solid State Relays
Description
SSR RELAY SPST-NO 25A 24-280V
PDF
/
Buying Options
Total Price: USD $48.04
Unit Price: USD $48.042516
≥1 USD $48.042516
≥10 USD $45.323126
≥100 USD $42.757666
≥500 USD $40.337419
≥1000 USD $38.054177
Inventory: 1252
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Width 45.7mm
Length 45.7mm
Height 33mm
Technical
Isolation Voltage 4kV
Load Current 25A
Input Current 10mA
RMS Current (Irms) 25A
Voltage - Load 24V~280V
Relay Type Relay
Max Surge Current 600A
Max Voltage Rating (DC) 32V
Throw Configuration SPST
Output Current 25A
Voltage - Input 3V~32VDC
Leakage Current 1mA
Insulation Resistance 1GOhm
Circuit SPST-NO (1 Form A)
Operating Supply Voltage 280V
Output Type AC
Approval Agency CE, CSA, UL, VDE
Voltage - Rated AC 280V
Termination Style Screw Terminal
Current Rating 25A
Depth 58.4mm
Min Operating Temperature -40°C
Max Operating Temperature 80°C
Termination Screw
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series CW24
Published 2004
Packaging Bulk
Physical
Number of Pins 4
Package / Case Hockey Puck
Mounting Type Chassis Mount
Mount Chassis Mount, Panel, Screw
Supply Chain
Factory Lead Time 5 Weeks
