CSD2450
RoHS
/
Package Hockey Puck
Category Relays / Solid State Relays
Description
SSR, 50A, 3.5-15VDC, 24-280VAC, ZERO
PDF
/
Buying Options
Total Price: USD $283.1
Unit Price: USD $283.095375
≥1 USD $283.095375
≥200 USD $112.957977
≥500 USD $109.18339
≥1000 USD $107.317759
Inventory: 6116
Minimum: 1
-
+
Technical Details
Physical
Mount Chassis Mount, Panel, Screw
Mounting Type Chassis Mount
Package / Case Hockey Puck
Number of Pins 4
Technical
Packaging Bulk
Published 2003
Series CSD
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Termination Screw
Max Operating Temperature 80°C
Min Operating Temperature -40°C
Current Rating 50A
Termination Style Screw Terminal
Voltage - Rated AC 280V
Approval Agency CE, CSA, UL, VDE
Output Voltage 280V
Output Type AC, Zero Cross
Max Output Current 50A
Circuit SPST-NO (1 Form A)
Voltage - Input 3.5V~15VDC
Output Current 50A
Throw Configuration SPST
Max Output Voltage 280V
Relay Type Relay
Voltage - Load 24V~280V
Input Current 15mA
Load Current 50A
Isolation Voltage 4kV
Max Supply Voltage (AC) 280V
Min Supply Voltage (AC) 24V
Dimensions
Height 58.4mm
Length 45.7mm
Width 22.9mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
